Rosemary Kilmer, W. Otie Kilmer

Construction Drawings and Details for Interiors (eBook, PDF)

• Format: PDF

Produktbeschreibung

CONSTRUCTION DRAWINGS AND DETAILS FOR INTERIORS DISCOVER FOUNDATIONAL CONCEPTS AND THE LATEST DEVELOPMENTS IN INTERIOR CONSTRUCTION DOCUMENTS In the newly revised Fourth Edition of Construction Drawings and Details for Interiors, distinguished interior design professors Rosemary Kilmer and W. Otie Kilmer deliver a comprehensive and practical perspective on the preparation and understanding of construction documents. The authors use a highly visual presentation and offer extensive sample drawings and details, as well as photographs, to show readers the fundamentals of drafting, drawing types, plans, and schedules, and computer-aided design. The Fourth Edition includes new sections on contract administration, field measuring tools, safety and security, and smart systems and controls. A companion website offers PowerPoint lecture slides, an instructor's manual, activities, test questions, and solutions. New appendices feature examples of interior design projects and common symbols for construction drawings. The book also includes: * A thorough introduction to drawing communication, equipment, and classification systems, including information about Building Information Modeling and building certification programs for sustainability * A discussion of green building certification programs * An exploration of the design process, including concept development, hand sketching, design development, preliminary designs, sketches, and presentations * A practical review of contract documents, including specifications, contracts, construction drawings, as-built drawings and demolition plans, and floor plans * An in-depth examination of structural, mechanical, and plumbing systems Construction Drawings and Details for Interiors is perfect for interior design students, early-career professionals hoping to improve their understanding of project drawing conventions, or anyone studying for the NCIDQ exam.

---

Dieser Download kann aus rechtlichen Gründen nur mit Rechnungsadresse in A, B, BG, CY, CZ, D, DK, EW, E, FIN, F, GR, HR, H, IRL, I, LT, L, LR, M, NL, PL, P, R, S, SLO, SK ausgeliefert werden.

Produktdetails

• Verlag: John Wiley & Sons
• Seitenzahl: 480
• Erscheinungstermin: 16. August 2021
• Englisch
• ISBN-13: 9781119714392
• Artikelnr.: 62473148

Autorenporträt

ROSEMARY KILMER, ASID, IDEC, LEED¯®AP, RID is Professor Emeritus of Interior Design at Purdue University. She has served on the Board of Directors for the NCIDQ exam and is a member of the American Society of Interior Designers. W. OTIE KILMER, AIA, is Professor Emeritus of Interior Design at Purdue University. He is an architect and interior designer who has worked with several high-profile, international design firms. Rosemary and Otie Kilmer also wrote Designing Interiors, Second Edition.

Inhaltsangabe

Acknowledgments xi

Part 1 Drawing Communication, Equipment, Fundamentals, and Classification Systems 1

Chapter 1. Design as Communication 3

Drawing for Idea Generation 3

Drawing as Design and Presentation Media 4

Drawing as a Guide for Construction 6

Issues Affecting How Interior Designers Communicate 6

Chapter 2. Drafting Equipment and Its Care 19

Drawing Tables and Surfaces 20

Drawing Papers and Plastic Film 21

Pencils, Leads, and Pens 22

Parallel Bar, T-square, and Drafting Machines 25

Triangles, Templates, and Compasses 27

Scales 28

Erasers, Erasing Shields, and Brushes 32

Additional Equipment 35

Chapter 3. Drawing and Drafting Fundamentals 37

Drawing 37

Drafting 38

Lettering 44

Starting the Drawing 47

Drafting Standards, Abbreviations, and Symbols 52

Chapter 4. Drawing Classification Systems 57

Multiview Drawings 57

Single-View Drawings 60

Axonometric Projections 62

Oblique Projections 64

Perspective Drawings 65

Part 2 The Design Process: Transition from Concepts to Construction Drawings 75

Chapter 5. Concept Development and the Design Process 77

The Design Process: The Analysis Phase 78

The Synthesis Phase 80

Test Fit Plans 85

Part 3 Contract Documents 95

Chapter 6. Construction Drawings, Specifications, and Contracts 97

Specifications 98

Contracts 103

Contract Administration 103

Construction Drawings 108

Guidelines for Preparing Construction Drawings 114

Drawing Conventions and Representations 123

Modular Units 135

Chapter 7. As-Built Drawings and Demolition Plans 139

As-Built Drawings 139

Demolition Plans 148

Chapter 8. Floor Plans 155

Floor Plans in Modular Units 158

Wall and Partition Types and Construction 163

Scale of Floor Plans 167

Drafting Standards 168

Walls in Plan View 169

Doors and Windows in Plan View 169

Graphic and Text Notation on Floor Plans 177

Architectural Symbols 178

Dimensioning Floor Plans 180

Designation of Materials 183

Chapter 9. Building Codes, Fire, and Life Safety Plans 193

Building Code Compliance 193

Fire and Life Safety Plans 200

Chapter 10. Elevations 205

Exterior Elevations 205

Interior Elevations 206

Scale of Interior Elevations 207

Drafting Standards for Interior Elevations 208

Designation of Materials 212

Dimensioning Elevations 213

Chapter 11. Sections 225

Types of Section Drawings 225

Scale of Section Drawings 228

Drafting Standards 231

Building Sections 232

Sections of Interior Spaces 234

Wall Sections 235

Detail and Object Sections 238

Chapter 12. Specialty Drawings 241

Purpose Of specialty Drawings 241

Stairs and Ramps 241

Millwork 250

Cabinetry 256

Fireplaces 263

Chapter 13. Door andWindow Schedules 271

Doors 271

Door Classifications: Operation, Types, and Materials 271

Door Hardware 276

Door and Hardware Schedules 279

Windows 287

Window Schedules 288

Chapter 14. Finish Schedules and Finish Plans 293

Room-Finish Schedules 295

Finish Plans 297<
