A High-Efficiency Switched Capacitor Point-Of-Load DC-DC Converter Switched Capacitor
-
- Englisch ausgewählt
35,99 €
inkl. gesetzl. MwSt.,
Beschreibung
Produktdetails
Einband
Taschenbuch
Erscheinungsdatum
11.12.2020
Verlag
LAP LAMBERT Academic PublishingSeitenzahl
72
Maße (L/B/H)
22/15/0,5 cm
Gewicht
125 g
Sprache
Englisch
ISBN
978-620-3-19646-7
This book encompasses the complete successful design, fabrication, and test of a CMOS-based SC dc-dc converter, addressing the ubiquitous 12-1.5 V board mounted point-of-load application.The traditional inductor-based buck converter has been the default design for switched-mode voltage regulators for decades. Switched capacitor (SC) dc-dc converters, on the other hand, have traditionally been used in low-power (<10 mW) and low conversion ratio (<4:1) applications where neither regulation nor efficiency is critical. In particular, the circuit developed in this study attains higher efficiency (92% peak, and >80% over a load range of 5 mA to 1 A) than surveyed competitive buck converters, while requiring less board area and less costly passive components. The topology and controller enable a wide input range of 7.5-13.5 V. Controls based on feedback and feed forward provide tight regulation under worst case line and load step conditions. This study shows that the SC converter can outperform the buck converter, and thus, the scope of SC converter application can and should be expanded.
