Investigating the Use of Frequency Selective Surfaces in High Power Microwave Applications
Versandkostenfrei!
Versandfertig in über 4 Wochen
56,99 €
inkl. MwSt.
PAYBACK Punkte
28 °P sammeln!
This thesis explores new territory with the theoretical investigation of the use of FSS in HPM applications. Work was performed in a simulation environment where rectangular and ring-shaped FSS elements were evaluated. Incident electric field levels of 0.5MV/m were propagated toward the FSS in a plane wave that was perpendicular to the surface. Results show that the total electric field in the apertures of the FSS can reach more than 6MV/m. This necessitates the use of high strength dielectric materials surrounding the FSS to reduce the risk of electrical breakdown. It is shown that a dielectr...
This thesis explores new territory with the theoretical investigation of the use of FSS in HPM applications. Work was performed in a simulation environment where rectangular and ring-shaped FSS elements were evaluated. Incident electric field levels of 0.5MV/m were propagated toward the FSS in a plane wave that was perpendicular to the surface. Results show that the total electric field in the apertures of the FSS can reach more than 6MV/m. This necessitates the use of high strength dielectric materials surrounding the FSS to reduce the risk of electrical breakdown. It is shown that a dielectric of only 2.5mm thick on each side of the FSS eliminates the risk of breakdown.
