Construction and Testing of Broadband High Impedance Ground Places for Surface Mount Antennas
Versandkostenfrei!
Versandfertig in über 4 Wochen
29,99 €
inkl. MwSt.
Weitere Ausgaben:
PAYBACK Punkte
15 °P sammeln!
The purpose of this research was to design and build appropriate broadband high impedance ground planes for surface mount antennas. Broadband, low-profile antennas, such as spirals, log-periodics, and bow-ties, suffer substantially in gain and bandwidth performance when they are brought close to a conducting surface. Thus, when standard broadband antenna designs are conformally placed on vehicle bodies, they can no longer achieve the high data rates required by modern communication. A simple remedy for this has been to place an absorber lined cavity behind the antenna to preserve some bandwidt...
The purpose of this research was to design and build appropriate broadband high impedance ground planes for surface mount antennas. Broadband, low-profile antennas, such as spirals, log-periodics, and bow-ties, suffer substantially in gain and bandwidth performance when they are brought close to a conducting surface. Thus, when standard broadband antenna designs are conformally placed on vehicle bodies, they can no longer achieve the high data rates required by modern communication. A simple remedy for this has been to place an absorber lined cavity behind the antenna to preserve some bandwidth, at the expense of reduced gain. However, recently introduced high impedance ground planes have novel electromagnetic features that have been shown to improve conformal antenna performance without the detrimental effects of absorber losses. In this research, first, square patch ground planes for narrowband antennas were built and analyzed. Second, a log-periodic broadband antenna was analyzed with square and circular patch ground planes. Finally, two novel triangular-patch high impedance ground plane designs as a meta-substrate for a broadband bow-tie antenna were presented. Consequently, the high impedance ground plane provided a suitable platform for the bow-tie with removing the undesired effects of a regular metallic ground plane. Results indicated that the novel designs have better gain than the bow-tie in free space, and the bow-tie over a metallic surface. This work has been selected by scholars as being culturally important, and is part of the knowledge base of civilization as we know it. This work was reproduced from the original artifact, and remains as true to the original work as possible. Therefore, you will see the original copyright references, library stamps (as most of these works have been housed in our most important libraries around the world), and other notations in the work. This work is in the public domain in the United States of America, and possibly other nations. Within the United States, you may freely copy and distribute this work, as no entity (individual or corporate) has a copyright on the body of the work. As a reproduction of a historical artifact, this work may contain missing or blurred pages, poor pictures, errant marks, etc. Scholars believe, and we concur, that this work is important enough to be preserved, reproduced, and made generally available to the public. We appreciate your support of the preservation process, and thank you for being an important part of keeping this knowledge alive and relevant.
