Compact Multi-Coil Inductive Power Transfer System with a Dynamic Receiver Position Estimation
Versandkostenfrei!
Versandfertig in 6-10 Tagen
12,90 €
inkl. MwSt.
PAYBACK Punkte
0 °P sammeln!
Inductive power transfer (IPT) systems intolerance to misalignment limits their ability to transfer energy to objects with flexible or dynamic position. In this thesis, a novel misalignment tolerant multi-coil design is proposed for supplying stationary and dynamic battery-free wireless devices. A compact architecture composed of individually switchable 3 layers of printed coils arranged with overlap for excellent surface coverage. A hybrid architecture based on three compact AC supply modules reduces the supply circuit complexity on the sending side. The sending side activation procedure is b...
Inductive power transfer (IPT) systems intolerance to misalignment limits their ability to transfer energy to objects with flexible or dynamic position. In this thesis, a novel misalignment tolerant multi-coil design is proposed for supplying stationary and dynamic battery-free wireless devices. A compact architecture composed of individually switchable 3 layers of printed coils arranged with overlap for excellent surface coverage. A hybrid architecture based on three compact AC supply modules reduces the supply circuit complexity on the sending side. The sending side activation procedure is based on a measurement of the transmitting coils voltage and the communication between both sides to distinguish a valid device from other conductive objects and to ensure a secure operation. By a prediction of the next position of the receiver, a continuous energy transfer is realized, which is suitable for battery-free devices.The experimental results prove that the proposed architecture has a good performance for different trajectories when the device speed does not exceed 15 mm/s. Besides, the maximum detection time for the initial device position is about 1.6 s. The maximal time interval to check the transmitter coils is around 0.7 s. The proposed architecture reduces the circuit footprint by a factor of 62% compared to common architectures.
