BEAM STEERING ARRAY ANTENNA
Versandkostenfrei!
Versandfertig in 6-10 Tagen
29,99 €
inkl. MwSt.
PAYBACK Punkte
15 °P sammeln!
Antennas play an integral part in wireless communication system. Microstrip patch antennas are versatile in terms of their geometrical shapes and implementations. Inhibiting characteristics of a single microstrip patch, like low gain and smaller bandwidth, make it more popular for array configuration. The aim of this work is to design and implement a microstrip phased array antenna, printed on a composite ferrite-dielectric substrate. Two rectangular radiating patches on a low dielectric constant substrate are arranged in linear configuration to achieve required radiation properties. The micro...
Antennas play an integral part in wireless communication system. Microstrip patch antennas are versatile in terms of their geometrical shapes and implementations. Inhibiting characteristics of a single microstrip patch, like low gain and smaller bandwidth, make it more popular for array configuration. The aim of this work is to design and implement a microstrip phased array antenna, printed on a composite ferrite-dielectric substrate. Two rectangular radiating patches on a low dielectric constant substrate are arranged in linear configuration to achieve required radiation properties. The microstrip array feeder network, consisted of integrated power divider and phase shifters, is used. Tunable progressive phase shift is produced by varying the magnetic bias that changes the permeability of ferrite material, which in turn changes the phase velocity and, hence, the insertion phase of the propagating microwave signal. The two-way power splitter is attained power dividers, which improves the isolation and matching of the ports. The antenna array is designed using standard equations and simulated by professional software called, High Frequency Structural Simulator (HFSS).
